Starting Torque: 0.5Hz 100%

Speed Adjustable Range: 1:100

Speed-holding precision: ±1.0%

Overload Capability: 150% rated current for 60s; 180% rated current for 1s

Acceleration/deceleration Time: 0.1-3600s

Starting Frequency: 0.01~10.00Hz

Input Voltage: 220V/380±15%

Input Frequency Range: 50/60Hz, fluctuation±5%

Output Voltage: 0-rated input voltage

Output Frequency: 0-200Hz

Programmable Digital Input: 2 way of digital terminal input

Programmable Analog Input: V:0-5V; V(remote pressure gauge):0-10V; C (pressure transducer ):4-20mA

Replay Output: 1 way output, programmable

Open Collection Output: 1 way output, programmable

Installation: Installation should be executed under the conditions of no direct sunlight, dust, corrosive gas, inflammable gas, oil mist, steam and water drop

Altitude: Lower than 1000m, service in derated capacity above 1000m. Derate 1% capacity every 100m increase in temperature

Environment Temperature: -10℃-+40℃, service in derated capacity for 40℃-50℃. Derate 4% capacity every 1℃ increase in height

Humidity: ≤95%RH, no water condensation.

Vibration: <5.9m/52(0.6G)

Command Running Channel: Three kinds of channels: 1. Operational panel 2. Control terminal, 3. Serial communication port, choose 1 and 2 for master drive and 3 for auxiliaries

Built-in PID: Advanced PID arithmetic to realize closed loop control system

Stall Speed Control: Automatically limit current and voltage at running period to prevent tripping due to frequent overcurrent or overvoltage

Master and Auxiliaries connection: Extensible RS485 design, one drive in the system can be master and controls the other auxiliary drives (4 at most) to work by communication mode, Master drive sends PID feedback information to the auxiliary drives and monitors status of auxiliaries in real time. Any failure of the auxiliary drives does not affect the others

Water Shortage Protection: If the drive detects the pipe pressure is lower than the water shortage pressure set value, the system stops working automatically. After set period time, it restarts automatically for specified times. If pressure restores to normal, system works normally, otherwise, system stops automatically in case of idle running of pump and prolongs pump lifetime to the maximum extent

High Pressure Alarm: When pressure exceeds set pressure, it stops running automatically to avoid damage on pipe network due to high pressure

Automatic Energy-saving Running: Automatically lower output voltage under light loading to save energy

Password Setting: 4-bit password can be set with non-zero numbers, Exit password setting interface and the password will be valide in 1 minute

Parameters Locking: Define whether the parameter is locked in running or stopped status in case of misoperation
